Akuvox A08S Slimline Access Unit

  • Slim​ format housing – ideal for limited space installation locatrions such as door frames / door mullions
  • Aluminum body​
  • Multiple access control authentication (RFID, NFC, Bluetooth, PIN code)​
  • QR code scanning​ for ‘temporary key’ access
  • 1 port interface for Relay out​
  • Wiegand (W26/W34/W58) protocol​
  • BLE 5.0​
  • IK07 & IP65 for outdoor / high impact locations

We offer online price beat guarantee, Please contact us for price or add item to Quote Request.

View List

Description

Akuvox A08S mullion-style access control reader is ideal for both residential and office controlled access applications; the narrow, sleek design makes it ideal for locations with limited spaces – particularly doors frames.

Available with a variety of authentication methods including RFID, NFC, Bluetooth, QR Code scanning and PIN keypad authentication, the Akuvox A08S also supports dual authentication for increased security.

With IP65 and IK07 protection ratings, the A08 access reader is suitable for both indoor and outdoor location.

Features

  • Slim​ format housing – ideal for limited space installation locatrions such as door frames / door mullions
  • Aluminum body​
  • Multiple access control authentication (RFID, NFC, Bluetooth, PIN code)​
  • QR code scanning​ for ‘temporary key’ access
  • 1 port interface for Relay out​
  • Wiegand (W26/W34/W58) protocol​
  • BLE 5.0​
  • IK07 & IP65 for outdoor / high impact locations

Specifications

Front shell material Surface tempered glass/shell aluminum panel 5052
Back shell material PC
IP Rating IP65
IK Rating IK07
Flash 128MB
RAM 64MB
Network Port 1RJ45, 10/100Mbps adaptive
Power Input 12V/1A DC
Power Output 12V/ max 500mA
Camera Angle FOV:77.1°
Power Consumption Not higher than 12W
Operating temperature -20~+55 degrees Celsius
Storage temperature -30~+70 degrees Celsius
Working Humidity 10%~95%
Dimensions 140 (H) x 50 (W) x 26.7 (D) mm
Weight (Net) 0.80kg
Weight (Gross) 0.80kg

Akuvox A08 Datasheet

Accessories

Downloads

Akuvox A08 Datasheet
