Akuvox S565 – 10″ Linux Indoor Monitor

  • 10″ touch screen with 1280 x 800 resolution
  • Complies with SIP Standards
  • Stylish industrial design
  • Two way audio communication
  • Built in Wi-Fi Option
  • Eight channel inputs, one built in relay
  • PoE or External power
  • Desk Mount option
View List
Compare

Description

Akuvox S565 is a cost effective 10 inch intercom call answering panel running on Linux Operating System with optional Wi-Fi and Desk Top Mounting stand. It delivers the ultimate touch screen experience in an unobtrusive, space-saving design featuring a brilliant 10-inch capacitive touch screen display.

Features

  • 10″ touch screen with 1280 x 800 resolution
  • Complies with SIP Standards
  • Stylish industrial design
  • Two way audio communication
  • Built in Wi-Fi Option
  • Eight channel inputs, one built in relay
  • PoE or External power
  • Desk Mount option



Akuvox S565 Datasheet

Specifications

Description S565W
Display 10 Inch IPS LCD 1280×800 resolurion
Screen 10 Inch capacitive touch screen
Wi-Fi IEEE802.11 b/g/n, @2.4GHz
RS485 port Support
Relay out 1
Bell in 1
I/O 8
Front panel Plastic
RAM / ROM 128MB / 256MB
Microphone Dual microphones
Speaker One speaker
Ethernet Ports 2xRJ45,10/100Mbps adaptive
POE 802.3af Power-over-Ethernet
Power 12V DC Connector
Installation Wall-mounted & Desktop
Dimension 278x164x22.8 mm
Working Humidity 10~90%
Working Temperature -10°C ~ +45°C
Storage Temperature -20°C ~ +70°C

Accessories

Downloads

Akuvox S565 Datasheet
