Akuvox C317S / W – Android 10 inch monitor with optional Wi-Fi

Android slimline touch screen monitor

  • Ultra clear, stylish thin profile design
  • 10” capacitive touch screen with energy saving mode
  • Optional 1MP CMOS camera
  • Optional Wi-Fi (2.4GHz, IEEE802.11 b/g/n)
  • Reception of a HD picture from the door communicator
  • Two-way communication with other units in the network, based on SIP v2.0 protocol
  • Supports Video Preview – allows you to see your visitor before answering call
  • Android operating system allows easy integration with 3rd party apps
  • Powered by PoE or external source for easy and convenient installation
  • Supports US or European electrical wall box mounting

Akuvox C 317 – 10 inch monitor with optional Camera and Wi-Fi is available in 2 models.

We offer online price beat guarantee, Please contact us for price or add item to Quote Request.



Clear
View List

Description

Akuvox C317S / W – 10 inch monitor with optional Wi-Fi  running Android operating system supports 3rd party apps and provides audio and video communication with Door phones via SIP 2.0 protocol. It delivers the ultimate touch screen experience in an unobtrusive, space-saving design featuring a brilliant 10 inch capacitive touch screen display.

Features

  • Ultra clear, stylish thin profile design
  • 10” capacitive touch screen with energy saving mode
  • Optional 1MP CMOS camera
  • Optional Wi-Fi (2.4GHz, IEEE802.11 b/g/n)
  • Reception of a HD picture from the door communicator
  • Two-way communication with other units in the network, based on SIP v2.0 protocol
  • Supports Video Preview – allows you to see your visitor before answering call
  • Android operating system allows easy integration with 3rd party apps
  • Powered by PoE or external source for easy and convenient installation
  • Supports US or European electrical wall box mounting

Akuvox C317S / W can operate as standalone or integrate with IP Phone systems for extra user convenience, it also comes with PoE or Wi-Fi for easy and cost effective installation. Ability to add 3rd party android apps for Home Automation etc. makes the Akuvox C317S a powerful multi-function communicator for Smart Homes.

Akuvox C317S / W also supports integration with Akuvox Smartplus cloud intercom service.

Akuvox C317S Datasheet

Specifications

Description C317S
Touch Screen Display Normally black, Transmissive, Projected Capacitive, Luminance 350 cd/m²
LCD Size 10 inch (Diagonal)
Display Aspect Ratio 16:9
Display Resolution 1280 x 800
Contrast Ratio 800:1
Screen Viewing Angle ±89° Left, ±89° Right, ±89° Upper, ±89° Lower
Audio Features Built-in microphone and speaker (For C317A and C317W only)
Video Streaming Formats H.264
Memory RAM 2GB, ROM 8GB
Ethernet 2×10/100 Mbps ports, auto-switching, auto-discovery, auto-negotiating, full/half duplex, DHCP, IEEE802.3af compliant
RS485 1 RS485 port
Alarm Support 8 channels input
Relay Out 2 Relay Out (NO/COM/NC)
Bell In 1 Bell In
Memory Slot 1 Micro SD slot
Operating Temperature -10° to 45°C
Housing Material Plastic
Dimensions 251(W) x 182.5(H) x 22(D) mm
Weight (Net) 1.00kg
Weight (Gross) 1.50kg

Additional information

Weight 1.5 kg

Accessories

PoE Switch

Downloads

Akuvox C317S Datasheet
